Laboratory Equipment
| High-speed camera | Laser vibrometer |
|---|
| PHANTOM MIRO C110 8GB MEMORY, MONO | Polytec PDV-100 8GB MEMORY, MONO |
| High speed camera Phantom TMX 7510 | High speed camera Phantom T 4040 |
|---|
| |
| High speed infrared camera FLIR X6981HS SLS |
|---|
|
| Doppler radar system BR 1001 | Doppler radar system BR 3502 |
|---|
| |
Acoustic emission
Vallen AMSY-6 MB2 with dedicated software
| Doppler radar | Electromagnetic inductor |
|---|
| LABRADAR | Modal Shop 2075E |
Analysers
| 2x Simcenter SCADAS XS | SIRIUSi 6xACC, 2xACC+ |
|---|
| Simcenter SCADAS XS | SIRIUSi 6xACC, 2xACC+ |
Modal hammers
| model 086D50 | model 086D20 | model 086D05 |
|---|
| model 086D50 | model 086D20 | model 086D05 |
Single and tri axial sensors
- Triaxial accelerometers ICP® 356A15
- Force sensor 208C03 ICP®
- Prepolarized free-field condenser microphone PCB model 378B02, 1/2"
- Acceleration sensor 100 000g PCB model 350B01
- Single axis acceleration sensor PCB model 352A21/NC
- Triaxial acceleration sensor Endevco 35C-10-X
- Accelerometer Seat Pad 606M2 A
Software
Software for modal analysis
| |
|---|
| Test.Xpress i Test.Lab | DweSoft X3 |
Software acessed from academic network
| | |
|---|
| ABAQUS | ANSYS | MATHEMATICA |
| FLEXPRO 2019 | ORIGIN | MATLAB |
| Inventor | |
Software for analyzing camera images
| Ballistic DIC system with Mercury RT software | FLIR Research Studio Pro |
|---|
| |
